I618A-M Wireless Visitor Chime with Door-Opening Control
Sold: 11361 sản phẩm
596.000 ₫ (VAT included)
I618A-M Wireless Visitor Chime with Door-Opening Control
Sensor:
- Sensor Power Supply: 3 × AAA batteries or 5V power from a phone charger
- Power Jack: Standard micro USB port
- Body Heat Detection Range: 4–6m radius
- Detection Angle: 110° horizontal, 30° vertical
- Rear ON/OFF switch
- Window cover slot to reduce false alarms
Wireless Chime:
- Chime Power Supply: 110–220V
- Chime Tones: 32 melodies
- Chime Tones: 32 melodies
- Transmission Frequency: 433MHz
- Distance from Sensor to Chime: 20–50m with obstacles; 50–100m without obstacles, depending on wireless environment at installation position
- Supports pairing 6–10 sensors to 1 chime; 1 sensor can be paired with multiple chimes
- Supports adding up to 6 RM4A remotes for remote ON/OFF, tone selection and volume adjustment within 20–50m
- Remote Functions: ON / OFF / Change Chime Tone / Volume Up and Down
M4 Magnetic Door Sensor:
- Battery: CR0232-3V CMOS battery
- Battery: CR0232-3V CMOS battery
- Signal Transmission Distance: 20–50m, depending on obstacles
I618A-M VISITOR NOTIFICATION AND DOOR-OPEN ALARM CONTROL SOLUTION
The I236S wireless visitor chime I618A uses an intelligent U.S.-designed microcontroller and highly sensitive RF433MHz wireless communication. It can be integrated with the M4 magnetic door sensor to monitor and provide an alarm when a display cabinet or door is opened. This solution is suitable for product display areas and provides both visitor notification and anti-theft protection for retail stores. RF433MHz signals can transmit effectively through common obstacles such as wood, glass, and thin walls. The signal receiving range is approximately 20–50m, depending on the installation environment and obstacles. The product is designed for a service life of more than 5 years and is covered by a warranty of up to 2 years.OUTSTANDING FEATURES OF THE I618A-M WIRELESS VISITOR CHIME WITH MAGNETIC DOOR ALARM
- The B8A chime receiver supports integration with approximately 6–10 wireless devices, including PIR sensors, magnetic door sensors, push buttons, chime transmitters, and remote controls. A dedicated SET button on the front panel makes pairing with additional accessories easier.
- M4 Magnetic Door Sensor: compact design with high sensitivity. When the gap between the two magnetic sensor parts reaches approximately 1cm, the chime is immediately activated.
- The PIR sensor also includes a 5V power input. It can be powered using a standard mobile phone charger through a Micro USB port, helping reduce the cost of frequent battery replacement. The sensor is also designed with a cover slot that can help limit the detection angle and reduce false alarms.
BENEFITS AND APPLICATIONS OF THE KAWASAN I618A-M
The visitor sensor combined with the M4 magnetic door sensor is suitable for retail and display environments such as mobile phone stores, jewelry stores, convenience stores, and similar locations. It helps staff recognize when customers arrive while also providing timely warning if a display cabinet or protected door is opened unexpectedly.
Sensor:
- Sensor Power Supply: 3 × AAA batteries or 5V power from a phone charger
- Power Jack: Standard micro USB port
- Body Heat Detection Range: 4–6m radius
- Detection Angle: 110° horizontal, 30° vertical
- Rear ON/OFF switch
- Window cover slot to reduce false alarms
Wireless Chime:
- Chime Power Supply: 110–220V
- Chime Tones: 32 melodies
- Chime Tones: 32 melodies
- Transmission Frequency: 433MHz
- Distance from Sensor to Chime: 20–50m with obstacles; 50–100m without obstacles, depending on wireless environment at installation position
- Supports pairing 6–10 sensors to 1 chime; 1 sensor can be paired with multiple chimes
- Supports adding up to 6 RM4A remotes for remote ON/OFF, tone selection and volume adjustment within 20–50m
- Remote Functions: ON / OFF / Change Chime Tone / Volume Up and Down
M4 Magnetic Door Sensor:
- Battery: CR0232-3V CMOS battery
- Battery: CR0232-3V CMOS battery
- Signal Transmission Distance: 20–50m, depending on obstacles
WHY SHOULD YOU CHOOSE KAWASAN PRODUCTS?
Hiện nay, có rất nhiều loại chuông cửa và báo khách không dây khác nhau, đến từ nhiều thương hiệu. Để có thể chọn được sản phẩm, phù hợp nhất với nhu cầu sử dụng. Đồng thời đảm bảo được chất lượng sản phẩm, khách hàng cần lưu ý các điểm sau khi mua hàng:
- Choose a genuine and reputable brand: There are many reputable brands on the market, such as KAWASAN, Xiaomi, Abaro, and others, which are widely selected and trusted by users.
- Check labels and warranty information: When purchasing electrical or electronic products, customers should carefully check the product label, packaging information, and warranty seal to reduce the risk of purchasing counterfeit or low-quality goods. Reviewing product specifications before purchase also helps with comparison.
- Carefully consider durability, functions, operating performance, and user safety. Examine the product structure, functions, and operating instructions to distinguish high-quality products from imitations. Customers can also review technical specifications such as signal transmission range, water resistance rating, and integration capability. Counterfeit or low-quality wireless chimes may have several internal components omitted from the chime receiver, while the outer housing may be poorly manufactured and unable to provide adequate water resistance. Based on the information above, customers can choose the most suitable wireless chime for their needs.
Thank you for trusting Kawasan products!
Toll-Free Consulting Hotline: 1800 0058 Or Call Directly: 0911 757 234
Website: www.kawasan.com.vn
- Description
- Reviews (4)
Description
I618A-M VISITOR NOTIFICATION AND DOOR-OPEN ALARM CONTROL SOLUTION
The I236S wireless visitor chime I618A, dùng Chip vi xử lý thông minh của Mỹ và tần số sóng RF433 siêu nhạy. Tích hợp thêm cửa từ M4, kiểm soát và báo động mở cửa tủ. Phù hợp cho các khu vực trưng bày sản phẩm. Giải pháp báo khách và báo trộm hiệu quả hơn, cho các cửa hàng.
Tính chất sóng RF433 Mhz cảm biến xuyên vật cản tốt như: gỗ, kính, tường mỏng…Khoảng cách nhận tín hiệu từ 20-50m, tuỳ môi trường vật cản. Độ bền > 5 năm, chế độ bảo hành đến 2 năm. Nên người tiêu dùng hoàn toàn có thể tin tưởng, mua hàng của Kawasan
OUTSTANDING FEATURES OF THE I618A-M WIRELESS VISITOR CHIME WITH MAGNETIC DOOR ALARM
- The B8A chime receiver supports integration with approximately 6–10 wireless devices, including PIR sensors, magnetic door sensors, push buttons, chime transmitters, and remote controls. A dedicated SET button on the front panel makes pairing with additional accessories easier.
- M4 Magnetic Door Sensor: compact design with high sensitivity. When the gap between the two magnetic sensor parts reaches approximately 1cm, the chime is immediately activated.
- The PIR sensor also includes a 5V power input. It can be powered using a standard mobile phone charger through a Micro USB port, helping reduce the cost of frequent battery replacement. The sensor is also designed with a cover slot that can help limit the detection angle and reduce false alarms.
BENEFITS AND APPLICATIONS OF THE KAWASAN I618A-M
The visitor sensor combined with the M4 magnetic door sensor is suitable for retail and display environments such as mobile phone stores, jewelry stores, convenience stores, and similar locations. It helps staff recognize when customers arrive while also providing timely warning if a display cabinet or protected door is opened unexpectedly.
4 reviews for Bộ Báo Khách Không Dây Kết Hợp Kiểm Soát Mở Cửa I618A-M
Add a review
- Description
- Reviews (4)
Description
I618A-M VISITOR NOTIFICATION AND DOOR-OPEN ALARM CONTROL SOLUTION
The I236S wireless visitor chime I618A, dùng Chip vi xử lý thông minh của Mỹ và tần số sóng RF433 siêu nhạy. Tích hợp thêm cửa từ M4, kiểm soát và báo động mở cửa tủ. Phù hợp cho các khu vực trưng bày sản phẩm. Giải pháp báo khách và báo trộm hiệu quả hơn, cho các cửa hàng.
Tính chất sóng RF433 Mhz cảm biến xuyên vật cản tốt như: gỗ, kính, tường mỏng…Khoảng cách nhận tín hiệu từ 20-50m, tuỳ môi trường vật cản. Độ bền > 5 năm, chế độ bảo hành đến 2 năm. Nên người tiêu dùng hoàn toàn có thể tin tưởng, mua hàng của Kawasan
OUTSTANDING FEATURES OF THE I618A-M WIRELESS VISITOR CHIME WITH MAGNETIC DOOR ALARM
- The B8A chime receiver supports integration with approximately 6–10 wireless devices, including PIR sensors, magnetic door sensors, push buttons, chime transmitters, and remote controls. A dedicated SET button on the front panel makes pairing with additional accessories easier.
- M4 Magnetic Door Sensor: compact design with high sensitivity. When the gap between the two magnetic sensor parts reaches approximately 1cm, the chime is immediately activated.
- The PIR sensor also includes a 5V power input. It can be powered using a standard mobile phone charger through a Micro USB port, helping reduce the cost of frequent battery replacement. The sensor is also designed with a cover slot that can help limit the detection angle and reduce false alarms.
BENEFITS AND APPLICATIONS OF THE KAWASAN I618A-M
The visitor sensor combined with the M4 magnetic door sensor is suitable for retail and display environments such as mobile phone stores, jewelry stores, convenience stores, and similar locations. It helps staff recognize when customers arrive while also providing timely warning if a display cabinet or protected door is opened unexpectedly.
4 reviews for Bộ Báo Khách Không Dây Kết Hợp Kiểm Soát Mở Cửa I618A-M
-
Đã dùng vài tháng, cửa từ vẫn nhạy. Chỉ cần hé cửa chút là chuông nhận tín hiệu rồi.
-
Lắp khoảng 15p là xong, ko phải đi dây nên khỏe
-
Chuông có nhiều kiểu nhạc và chỉnh được âm lượng. Dùng cho cửa hàng rất chuyên nghiệp, có khách vào là biết ngay.
-
Dùng cho cửa hàng, vừa báo khách vừa hỗ trợ kiểm soát lúc cửa được mở
Add a review
